Jedi Dooku 'The Turn'

Introducing 'The Turn', Count Dooku's saber hilt from the Tales of the Jedi animated series.
This rendition is the version shown used by Dooku as a Jedi in the show.
Images and screenshots from the series were used to create an as accurate as possible replica of the famous Jedi turned to the darkside.
Hilt design and engineering done by Jimmy's Saber Junk, manufactured here at Saberbay.

This saber is 100% CNC machined from 6061 alumimum, and engineered to hide almost every required screw for assembly.
-363mm total hilt length (actual prop replica measures around 361mm)
-7/8" blade size required for emitter
-anodized and brushed aluminum finishes on the main body and shrouds
-black anodized and knurled sections in the grip
-polished brass trigger piece
-functional brass trigger for switch activation
-two button actuator function in the mid section for switch activation
-28mm bass speaker compatible

Empty hilt kits will include the high end replica saber, custom collector's box designed by Christian Cruz, and blade retention wrench

As of 2/3/23, this item is a PREORDER. Final production will likely take 2-3 months from this date. This is not an exact estimation and is subject to change.
Please make sure you are committed to your purchase before buying.
Half payment options are required to pay their remaining balance before receiving their orders. If you would like to pay the other half of your payment before the production is finished, please email the store at info@saberbay.com

Install chassis designed by Jimmy's Saber Junk for the 'The Turn' sold here at Saberbay.
Not intended for any other saber design.
This chassis is printed in black PLA+ filament, a total of 3 parts
Parts list for install:
-CFX, Proffie, GHV3 or Verso soundboard
-NPXL shortpin hiltside connector for emitter (V3 or ECO)
-removable 18650 battery(spring loaded contacts provided with chassis)
-Two 1.5mm brass tactile switches, you can use up to 4 switches if you also use the trigger for switch activations (switches included with chassis)
-ShtokCustomWorx Bluetooth BT909 breakout board (optional)
-28mm bass speaker
-high amp killswitch (optional, recommended)
-2.1mm recharge port (optional)
-ShtokCustomWorx Speaker PCB set (required for speaker pod)
-OLED screen (TCSS, KR, or Saberbay version compatible)

Install chassis designed by Jimmy's Saber Junk for the 'The Turn' sold here at Saberbay.
Not intended for any other saber design.
This chassis is printed in black PLA+ filament, a total of 5 parts(6 if you include the STL version which comes with the extra diffuser piece that can be printed in your own clear filament)
Parts list for install:
-Proffie or GHV3 soundboard
-NPXL shortpin hiltside connector for emitter (V3 or ECO)
-removable 18650 battery(spring loaded contacts provided with chassis)
-Two 1.5mm brass tactile switches, you can use up to 4 switches if you also use the trigger for switch activations (switches included with chassis)
-single BTF pixel accent LED for crystal chamber
-ShtokCustomWorx Medium Pixel Ring
-ShtokCustomWorx Bluetooth BT909 breakout board
-28mm bass speaker
-high amp killswitch (optional, recommended)
-2.1mm recharge port (optional)
-ShtokCustomWorx Speaker PCB set (required for speaker pod)

PAYMENT PLANS AVAILABLE
Send an email to ask about how to split your purchase into up to 4 separate payments.
Hilt purchase deposit is required upfront.

This is the installed version listing of this saber, 'The Turn'
Please read all information and specifics before ordering.
Lead times can take up to 6-8 weeks AFTER the run is finished. Leadtimes can be subject to change depending on volume.
Preordered installed versions will be NONREFUNDABLE, no questions asked.
In anticipation of your order, chassis parts and install parts are set aside in advance, order cancellations are not allowed.
Do not order unless you are 100% committed to your purchase and can afford it.

You can watch a video breakdown of this hilt here on Youtube, click the link HERE

This installed version uses the basic chassis design made for this saber, designed by Jimmy's Saber Junk. Please see some pictured examples in this listing (Proffie install, photos courtesy of Jimmy's Saber Junk)
Installed versions offered include the following choices:
-choice of soundboard of either CFX, Proffie, or GoldenHarvestV3
-optional add on for Bluetooth module compatibility for either CFX or Proffie
-optional add on for OLED screen compatibility for either CFX or Proffie
-choice of switch button placement (You can choose between the 4 different available switch areas for this saber, either the two located underneath the trigger, or two underneath the switch actuators in the middle of the hilt

Parts included with install:
-choice of soundboard installed
-NPXL V3 shortpin hiltside connector
-removable 18650 KeepPower 3000mah 15A protected cell battery
-two button setup (one for main power, second for auxiliary effects)
-high amp killswitch
-2.1mm recharge port
-28mm Saberbay X-BASS 4ohm/3W bass speaker
-OLED Screen Blue colored (if OLED add on chosen)
-SCW BT909 Bluetooth Breakout board module (if Bluetooth add on chosen)
-SCW speaker PCB set for removable speaker pod (required for recharge port and killswitch access)
