Battery Install Parts

High amperage kill switch used for lightsaber and prop builds using neo pixel
Wire this between battery positive and your soundboard.

Battery contact set for removable 18650 battery setups

Option 1: Larger set with spring side negative version.

Includes positive and negative tabs

Excess material can be cut off.

These measure 16.5mm in width

Option 2: Non spring negative set(larger negative tab, common for Goth3D chassis)

May need to trim the bottom stem off for your install.

Positive contact measures 12x11.2mm

Negative contact measures 14mmx6.4mm

Includes one of each contact only

Option 3: Non spring negative set(smaller footprint for negative tab)

Positive contact measures 12x11.2mm

Negative contact measures 10.3mmx6.4mm

Includes one of each contact only

Single lithium ion battery charging module.

Input voltage range: 5~6V

Output voltage: 4.2V

Charging current: 1A

Measures 12.5mmx15.5mmx3.5mm

Can be wired up to the battery as a "recharge port" using the USB-C connection. Please see the wiring diagram for proper wiring directions.



USB Type C port for data transfer and also charging with an additional TC4056 charging module.
Please not this is a TYPE C port and will not be compatible with non TYPE C plugs.

Please refer to the attached wiring diagram for suggested wiring when wiring to your soundboard, for both data transfer only and also for using the port also as a charger. The wiring diagram refers to a Proffie board can same schematic can be applied to different boards.



Smaller diameter version of the SCW Speaker/Battery PCB connector set.

Outer diameter is 17.5mm compared to the larger 20.5mm size.

Can be purchased with or without pins assembled(12 short pins included with unassembled version)

Has 4 different traces that can be used and soldered to:
-Battery +
-Battery -
-Speaker +
-Speaker -
(Speakers do not have polarity, this is just a separate trace to solder to)

Can also be repurposed for any other wiring feature that requires a detachable part with up to 4 different wires required

These are designed and manufactured by ShtokCustomWorx with the idea of using it as a way to have a "power pack".
Meaning you can remove a battery and speaker module using these PCBS.
Then can handle 15 Amps continuous, 20 Amps burst.
Supports 4 connections Battery +, Battery -, speaker + and speaker -.
These do not come with the pins already soldered on. The pins will need to be soldered in place.

***Does not include battery***
This is meant to be used with flat topped 18650 lithium ion batteries

It indicates the direction of positive and negative of the battery placement and won't cause damage if the battery is out in back wards

Some batteries may be very tight but most major brands will fit

These battery contacts are specifically used for the Force Ghost chassis design and also some other chassis designs from Shadowfoil Props

These are gold plated and can be used for 18650 button top batteries. Includes one of each contact per listing sale.



Designed and manufactured by ShtokCustomWorx, this is the horizontal version of a USB-C port. This also includes a small dust cover plug that can be used.
USB Type C port for data transfer and also charging with an additional TC4056 charging module.
Please not this is a TYPE C port and will not be compatible with non TYPE C plugs.

Please refer to the attached wiring diagram for suggested wiring when wiring to your soundboard, for both data transfer only and also for using the port also as a charger. The wiring diagram refers to a Proffie board can same schematic can be applied to different boards.
