The KR Sabers Verso v1.0 soundboard is designed to meet the needs of the entry-level saber user. Simple and easy to operate working right out of the box!
With SmoothSwing, high quality 16-bit sound and the ability to support NeoPixel LED strips or high power Tri-Cree XPE-2 LEDs, we feel this is the perfect option for you to begin your saber building journey!
Simply choose which config you would like and we will ensure the default settings for that config is on the SD card for you.
Listing includes 1 x Verso V1.0 and 1 x 16GB Micro SD Card.
>> LATEST MANUAL (APRIL 2020) CAN BE DOWNLOADED BY visiting TinyUrl.com/versoinfo <<
Latest firmware and default packages can be downloaded TinyUrl.com/versoinfo
Please note the latest firmware will be loaded onto the SD card for you. Solder the board first, ensuring your wiring is correct, then insert the SD card and boot the saber. The board will update to the latest firmware within 5 seconds. Sounds will play to indicate the update procedure is taking place.
If you need to download the full default SD card packages, then you can download the Tri Cree SD package here and the LED Pixel SD package here.
The recommended and authorised font maker is Kyberphonic Fonts. They can be contacted at their Facebook page here. https://www.facebook.com/Kyberphonic/
Featurs of the Verso include:
Dimensions: 18.9x29.9x4.5mm (+2.4mm longer with micro SD card)
Power supply: 3-5 Volts, up to 10A per LED channel output; single Li-Ion 3.6-3.7V (low 2.6V, full 4.2V) battery recommended
0.55 mA current consumption in Deep Sleep
3 high power LED channels
Speaker: 4 ohm or 8 ohm, 2W-5W
1 sound bank/font (Pre-loaded with Kyberphonic Fonts dedicated Verso font)
Unlimited blade color profiles
Sound FX (WAV sound files): boot, hum, swing, clash, ingnition, retraction
Light FX: ramp up, ramp down, fade, blade flickering, flash on clash
Micro SD card: 4-16Gb Class 4-10 by SanDisk brand recommended
3 Watts 5V powered sound amplifier, 16-bit digital output
44kHz or 22kHz WAV audio files sample rate
“SmoothSwing”, monophonic, polyphonic sound fonts support
APA102 (RGB), WS2812B (RGB), SK6812 (RGB, WWA) Neopixel/Pixelblade support
1/2/3-color LED stars (Tri-Cree LED modules) support
Easy and free firmware updates by user via micro-SD card
PLEASE NOTE: These boards will be fully tested and approved prior to shipping. It is highly recommended to have a professional saber builder install this board. If you wish to install yourself; it is at your own risk. KR Sabers or Saberbay cannot be held responsible for any damage to the board during installation. If there are any technical issues with the installation of the board please get in touch and we can assist you with troubleshooting. These boards will have a 90-day warranty.
Install chassis for 89Sabers OWK1 TPM hilt. 3D printed chassis comes in two parts. Top half holds the following parts: -NPVL V3 Long pin connector -NPVL V3 lens cover *older style* -brass tactile switches 1.5mm height -flat side PCB Rotary Chassis PCB set In order to install top half of chassis, silver plate must be removed from inside of the hilt first. Top half needs to be fully pressed all the way up and switch channels lined up with switch plunger holes. Always test fit your chassis before installing to ensure proper fitment and alignment of tactile switches.
Bottom half of chassis can hold the following parts: -Soundboard option chosen(CFX, Proffie, GHV3) -pin side PCB of Rotary Chassis PCB set -OLED screen(optional) -removable 18650 battery -battery contacts(provided with chassis) -22mm speaker (KR Sabers or Veco)
Please read to see what comes with each listing variation:
CHASSIS PARTS ONLY: 3D printed chassis parts to hold specified soundboard, brass tactile switches, and battery contacts. NO OTHER PARTS INCLUDED
PARTS + SOUNDBOARD: parts included with CHASSIS PARTS ONLY, as well as the soundboard itself with SD card, NPXL V3 Assembled Longpin connector, V3 older style lens, 18650 15A 3000mah Keeppower battery, OLED screen, Rotary Chassis PCB set with pins, 22mm KR Sabers speaker.
PARTS NO SOUNDBOARD: All parts listed above with the exception of NO SOUNDBOARD INCLUDED
From SaberTec you can now bring your own custom lightsaber alive by giving it a Golden Harvest heart! Allow us to provide you an unique experience and lift you into another galaxy!
This board will not require programming. You can make adjustments via the SD card.
The popular online configurator of the old version of the Golden Harvest will soon be available also for the GH v3 including a preview animation for Neopixel effects! To check out the full set of features of our Golden Harvest board, visit https://tinyurl.com/Ghv3features.
The Quick Setup Guide and the manual can be found here https://tinyurl.com/Ghdownload.
All boards are fully tested before shipping. Saberbay or SaberTec cannot be held responsible for any damage that arises from a faulty install or use of the board.
The sad card will be loaded with both configurations for your to choose one, for in hilt led illumination and pixel strip illumination.
If you have a Golden Harvest v3, you can use the Seedling USB Module for microUSB charging and file transfer. But even if you do not own a Golden Harvest v3, you can use it to charge a single Li-ion cell via microUSB. Using the Seedling USB Module you can charge a single Li-ion cell with up to 1.4A either via wall adapter or USB port of your computer. A smart charging algorithm automatically detects the maximum charging current your power source can provide and limits it to this amount. The Seedling USB Module contains a safe charging circuit. However, do not let your saber charge unsupervised! Safety always first! Please make also sure to use a protected 18650 Li-ion battery. For safe charging, use a Keeppower 18650 Li-ion battery. The Seedling USB Module can get very hot when you are charging at 1.4A due to its tiny dimensions (smaller than 11 mm x 19 mm / 0.433″ x 0.748″). It has an overtemperature protection, but please make sure that the environment in which you want to use it can handle high temperatures. Additional important information can be found in the manual of the Seedling. Please make sure to read it.
Manual found here: https://tinyurl.com/Ghseedling
All boards are fully tested before shipping. We cannot be held responsible for any damage that arises from a faulty install or use of the board.
